SLIK Bi-Folding Door Track and Gear Kit (For door sizes up to 1219mm & 1828mm)

Name: SLIK Bi-Folding Door Track and Gear Kit (For door sizes up to 1219mm & 1828mm)
Brand: Stormguard
SKU: S/SLIKFG

Code:

S/SLIKFG

Brand:

Stormguard

This item is out of stock and not available to purchase.

View alternative products

MATERIAL: Aluminium TrackTYPE: Folding Door GearSTYLE: Bi Fold Door Track KitFIXINGS: Pack includes all fixing screws required for installation Please note, next day delivery is available upon request. This SLIK bi-fold door kit allows doors to fold either sid...Read More

View full product details

View questions about this product

Create a wishlist

Sashikanta Padhi

Description

MATERIAL: Aluminium Track
TYPE: Folding Door Gear
STYLE: Bi Fold Door Track Kit
FIXINGS: Pack includes all fixing screws required for installation

Please note, next day delivery is available upon request.

This SLIK bi-fold door kit allows doors to fold either side of an opening leaving the floor clear for easy access.

Suitable for door widths up to 1219mm or 1524mm
Bi-fold kit includes top track with top pivot bracket, slide guide, top and bottom pivots, jamb brackets, hinges, door aligner and fixing screws
Designed for fitting doors to fold either side of an opening
Track can be easily cut down to suit 24" (610mm) 27" (686mm) 30" (762mm) door sizes
4'0" (1219mm) kit suitable for two or four doors
5'0" (1524mm) kit suitable for four doors only
Suitable for doors from 25mm to 34mm thick
The track can be cut to match your opening width.
This kit has been designed for 2 doors on each side of the opening. We do not recommend fitting more than 2 doors either side.

Tracks can be butted up together up to 8'0" (2438mm) length with 4 door leafs - please be aware that the track will need to be in the centre of the opening so it does not interfere with the operation of the slider.

Please note, handles are not included

Dimensions

Maximum weight per door: 15kg (33lbs) each
Maximum system weight: 60kg (132lbs)

Doors from 1" (25mm) to 1 3/8" (34mm) thick
Doors up to 2'0" (600mm) wide
4'0" (1219mm) kit suitable for two or four doors
6'0" (1524mm) kit suitable for four doors only
Suitable for doors from 25mm to 34mm thick

Top Track Length: 1219mm or 1524mm
Top Track Height: 20mm
Top Track Depth: 24mm

Specification

Dimensions

Size 1219mm (48")
1524mm (60")
1828mm

Details

Type Sliding Door
